Description
Features & Benefits
- Protects splices from water, corrosion, salt and moisture, provides strain relief
- Protects against added vibration in rugged environments
- Completely insulates and protects electrical connections
- Seamless butt connectors & brazed-seam rings & spades prevent unwanted opening of the connector barrel.
- Color-coded tubing with wire gauge imprint provides easy identification of the correct part for the job
- UL listed
- Lead-free solder has greater surface tension
- Solder stays in place which provides greater tensile strength than other solder sleeves
- Solder sleeves are pre-fluxed to clean metals & provide a quality solder termination
- New solder sleeves are Tin & Bismuth alloy
- 45° barrel allows installer to see wire is fully inserted and wire is crimped to terminal
- RoHS compliant; better for the environment
Technical Specifications
- Material: Polyolefin
- Color: Yellow
- Gauge: 12–10 GA
- Connection Type: Butt
- Operating Temperature: -67°F (-55°C) to 230°F (110°C)
- Standards: cUL
- Functions: Crimp, Solder & Seal
- Pack Quantity: 100
- Strength: 2200 PSI
- Shrink Ratio: 3:1
- Product Type: Butt Connector
- ROHS: Yes
- UL Listed: Yes
- Voltage Rating: 600 V
- Warranty: 1 Year
